C0XMO Botnet Spreads via DD-WRT Router Flaw, Kills Rival Malware

CVE-2021-27137 CVE-2015-2051 CVE-2022-35914 Gafgyt Variant IoT Botnet DDoS

Overview

A new Gafgyt botnet variant named C0XMO is actively compromising unpatched DD-WRT-based routers and other Linux-embedded devices by exploiting CVE-2021-27137, a stack buffer overflow in DD-WRT's UPnP service reachable over UDP port 1900. Once a device is compromised, C0XMO downloads architecture-specific payloads (ARM, MIPS, x86, PowerPC), establishes cron-based persistence, registers the device with its command-and-control infrastructure, and aggressively kills competing botnet processes and persistence mechanisms to maintain exclusive control. A modular Python scanner enables cross-platform lateral movement into D-Link routers, GLPI instances, Avtech DVR cameras, Zyxel devices, and Android devices via exposed ADB — significantly expanding the botnet's potential footprint. Enrolled devices are subsequently weaponized for DDoS operations supporting approximately 19 attack methods including UDP/TCP floods and NTP amplification.

Technical Specifications

Attribute	Details
Primary CVE	CVE-2021-27137 — DD-WRT UPnP stack buffer overflow (UDP 1900 / SSDP M-SEARCH)
Additional CVEs	CVE-2015-2051 (D-Link HNAP), CVE-2022-35914 (GLPI), CVE-2016-15047 / CVE-2025-34054 (Avtech DVR)
Malware Family	Gafgyt variant (C0XMO)
Target Architectures	ARM, MIPS, x86_64, PowerPC, Android (via ADB)
Payload Drop Locations	/tmp/.cache, /tmp/.sys, /var/tmp/.sys, /dev/shm/.sys
Persistence Mechanism	Cron jobs (re-execution every ~15 minutes)
C2 Infrastructure	85[.]215[.]131[.]70, 217[.]160[.]125[.]125:15527, 216.131.80.130/150/119
C2 Handshake	Magic string 669787761736865726500 + shared secret
DDoS Methods	~19 methods including UDP/TCP flood, NTP amplification, Cloudflare/UDP bypass
Lateral Movement	Python scanner (paramiko, requests, bs4) — SSH/Telnet brute-force + HTTP CVE exploitation
Distinguishing Behavior	Kills competing botnet processes and removes rival persistence (cron jobs, startup scripts)

Affected Products

• DD-WRT routers running firmware versions vulnerable to CVE-2021-27137 (UPnP stack buffer overflow) — primary entry point
• D-Link devices — HNAP command execution via CVE-2015-2051
• GLPI instances — code injection via CVE-2022-35914 (htmLawedTest.php)
• Avtech DVR cameras — authentication bypass / command execution via CVE-2016-15047 and CVE-2025-34054
• Zyxel devices — targeted by the Python scanner module
• Android devices — compromised via exposed Android Debug Bridge (ADB)

Attack Scenario

1. Target identification — C0XMO operators scan the internet for DD-WRT routers with UPnP enabled and UDP port 1900 accessible; victims are typically home users or small businesses running older DD-WRT firmware that has not been updated since before CVE-2021-27137 was patched

2. Initial exploitation — Crafted SSDP M-SEARCH packets with an oversized ST:uuid value are sent to the target router's UPnP service, triggering the CVE-2021-27137 stack buffer overflow and yielding unauthenticated remote code execution as root

3. Payload download and installation — The exploit shell retrieves an architecture-appropriate ELF binary (the C0XMO/Gafgyt payload) and drops it into /tmp/.cache or hidden directories (/tmp/.sys, /var/tmp/.sys, /dev/shm/.sys), sets executable permissions, and executes it

4. Persistence and C2 registration — Cron jobs are created to re-execute the payload every ~15 minutes; the malware connects to C2 servers using the magic handshake string, enrolling the device in the botnet

5. Rival malware elimination — C0XMO scans for other botnet binaries and persistence entries (Mirai/Gafgyt variants), terminates their processes, and removes their cron jobs and startup scripts to ensure exclusive control of the compromised device

6. Lateral movement and expansion — The Python scanner module (using paramiko, requests, bs4) begins brute-forcing Telnet/SSH with weak credentials and exploiting HTTP-based CVEs (GLPI, Avtech DVR, D-Link, Zyxel); it also attempts to compromise Android devices via exposed ADB; for each newly compromised host, the correct architecture-specific binary is downloaded and installed, growing the botnet across routers, IoT devices, DVRs, and Android endpoints

7. DDoS operations — Enrolled devices receive C2 commands to launch DDoS attacks against designated targets using any of ~19 supported methods, including UDP/TCP floods, NTP amplification, and Cloudflare bypass techniques

Impact

Individual Users and Small BusinessesOrganizations and ISPsSecurity Landscape

• Compromised routers and IoT devices become active DDoS botnet nodes, consuming available bandwidth, degrading internet performance, and risking ISP abuse complaints or service suspension
• C0XMO's cross-platform propagation means multiple devices in the same environment — router, DVR, IoT sensors, Android devices — may be simultaneously compromised, dramatically increasing cleanup complexity
• Device owners typically have no visible indication of compromise until performance degradation or ISP notification occurs

• Large numbers of C0XMO-enrolled devices can be directed to launch significant DDoS campaigns against internet services and critical infrastructure, with traffic appearing to originate from diverse consumer residential IP addresses
• Unmanaged or "forgotten" DD-WRT and IoT devices in corporate networks become stepping stones for lateral movement, particularly when they sit in sensitive or flat network segments adjacent to critical systems
• ISPs face increased abuse traffic volumes and support burden from customer devices enrolled in botnet operations

• C0XMO exemplifies continued Gafgyt-class botnet evolution: modular architecture, multi-architecture cross-platform payloads, reuse of old but widely unpatched CVEs (some dating to 2015), and active anti-competitor behavior that reduces botnet fragmentation on infected hosts
• The botnet highlights the persistent and systemic risk from legacy, unmaintained router firmware and the widespread failure to patch IoT and embedded devices — CVE-2021-27137 was disclosed in 2021, yet remains exploitable at scale in 2026
• High criticality for exposed DD-WRT and IoT environments (unauthenticated RCE + multi-CVE chain); significant ongoing availability threat at the ecosystem level

Mitigations

Patch and Configuration

• Update firmware — upgrade DD-WRT routers and all other affected devices (D-Link, GLPI servers, Avtech DVR cameras) to firmware and software versions that address the listed CVEs; replace hardware that no longer receives vendor security updates
• Disable UPnP where not explicitly required — disabling UPnP on routers eliminates the primary C0XMO entry point (CVE-2021-27137); at minimum, block external UDP port 1900 at the perimeter firewall to prevent internet-origin SSDP exploitation
• Lock down management interfaces — ensure router admin panels, Telnet/SSH, and Android ADB are not exposed to the internet; restrict access to internal or VPN-only segments; disable Telnet wherever possible and enforce SSH with key-based authentication

Network Monitoring and Detection

• Monitor for exploitation and botnet traffic indicators:
  • Unusual UDP 1900 traffic or spikes in SSDP M-SEARCH requests
  • Outbound connections to known C2 addresses: 85[.]215[.]131[.]70, 217[.]160[.]125[.]125:15527, 216.131.80.130/150/119 range
  • Unexplained high-rate outbound UDP/TCP flows consistent with DDoS participation
• Hunt for malware artifacts on routers, IoT, and Linux hosts:
  • Hidden directories: /tmp/.sys, /var/tmp/.sys, /dev/shm/.sys
  • ELF binaries with 755 permissions in /tmp and similar writable locations
  • Unexpected cron jobs executing at short intervals (e.g., every 15 minutes)

IoT and Router Environment Hardening

• Use unique, strong admin passwords and disable default or vendor-provided credentials on all network-connected devices
• Segment IoT and router management networks from core corporate and OT systems to prevent lateral movement from a compromised embedded device into sensitive infrastructure
• Maintain an asset inventory for all routers and embedded devices and include them in routine patch cycles and security review processes

Response if Compromised

• Factory-reset the device, then immediately flash the latest available firmware, reconfigure securely (disable UPnP, remote management, default accounts), and change all administrative credentials
• Rotate Wi-Fi and VPN credentials if the compromised router handled those services; monitor for recurring reinfection, which indicates other unpatched IoT devices in the environment are re-enrolling the cleaned host

Resources

Open-Source Reporting

• C0XMO Botnet Spreads via DD-WRT Router Flaw, Kills Rival Malware — BleepingComputer
• Inside Cross-Platform Propagation of New Gafgyt Variant C0XMO — Fortinet Threat Research
• C0XMO: A New Gafgyt Variant with Cross-Platform Propagation — SOC Prime
• New Gafgyt Variant Targets Multiple Linux Architectures — Cyber Security News

---

Last Updated: June 8, 2026
